Image Sequence

A canvas-based image sequence player with binary progressive loading for smooth playback.

Grafitty Can

Sentinel Bot

Rubber Duck

'use client'

import { useState } from 'react'
import { CanvasSequence } from '@/components/image-sequence'
import { cn } from '@/lib/utils'

const sequences = [
  {
    name: 'Grafitty Can',
    frameCount: 71,
    getImagePath: (idx: number) =>
      `https://qfxa88yauvyse9vr.public.blob.vercel-storage.com/sequence-01/Lata${String(idx).padStart(2, '0')}.webp`,
  },
  {
    name: 'Sentinel Bot',
    frameCount: 71,
    getImagePath: (idx: number) =>
      `https://qfxa88yauvyse9vr.public.blob.vercel-storage.com/sequence-02/Bot${String(idx).padStart(2, '0')}.webp`,
  },
  {
    name: 'Rubber Duck',
    frameCount: 71,
    getImagePath: (idx: number) =>
      `https://qfxa88yauvyse9vr.public.blob.vercel-storage.com/sequence-03/Ducky${String(idx).padStart(2, '0')}.webp`,
  },
]

function ImageSequenceDemo() {
  const [activeIndex, setActiveIndex] = useState(0)

  return (
    <div className="flex min-h-80 w-full items-center justify-center p-8">
      <div className="flex flex-wrap items-center justify-center gap-6">
        {sequences.map((seq, index) => {
          const isActive = index === activeIndex

          return (
            <div
              key={seq.name}
              className="relative cursor-pointer"
              onMouseEnter={() => setActiveIndex(index)}
            >
              <CanvasSequence
                frameCount={seq.frameCount}
                frameDuration={33}
                getImagePath={seq.getImagePath}
                objectFit="contain"
                isPlaying={isActive}
                resetOnPlay
                width={200}
                height={200}
                className="rounded-lg transition-opacity duration-200"
                style={{ opacity: isActive ? 1 : 0.5 }}
              />

              {/* Active frame indicator */}
              <div
                className={cn(
                  'pointer-events-none absolute inset-0 border-2',
                  isActive
                    ? 'border-primary opacity-100'
                    : 'border-transparent opacity-0'
                )}
              >
                <span className="bg-primary text-primary-foreground absolute top-0 -left-0.5 -translate-y-full px-1 py-0.5 font-mono text-xs uppercase">
                  {seq.name}
                </span>
              </div>
            </div>
          )
        })}
      </div>
    </div>
  )
}

export default ImageSequenceDemo

Installation

pnpm dlx shadcn@latest add @joyco/image-sequence

Usage

import { CanvasSequence } from '@/components/image-sequence'
<div className="h-[400px] w-[400px]">
  <CanvasSequence
    frameCount={71}
    frameDuration={33}
    getImagePath={(idx) => `/frames/frame_${String(idx).padStart(2, '0')}.webp`}
    className="size-full"
  />
</div>

Props

CanvasSequence

Prop	Type	Default	Description
`frameCount`	`number`	-	Total number of frames in the sequence
`frameDuration`	`number`	-	Duration of each frame in milliseconds
`getImagePath`	`(frameIndex: number) => string`	-	Function to generate the image URL for each frame
`width`	`number`	-	Optional wrapper width in CSS pixels
`height`	`number`	-	Optional wrapper height in CSS pixels
`isPlaying`	`boolean`	`true`	Whether the animation is playing
`isVisible`	`boolean`	`true`	Whether the canvas is visible
`loop`	`boolean`	`true`	Whether to loop the animation
`preload`	`boolean`	`true`	Whether to preload images on mount
`objectFit`	`'contain' \| 'cover' \| 'fill'`	`'contain'`	How the image fits in the canvas
`onFrameChange`	`(frameIndex: number) => void`	-	Callback when frame changes
`onAllFramesLoaded`	`() => void`	-	Callback when all frames are loaded
`timeTransform`	`(deltaTime: number) => number`	-	Transform delta time for speed control
`devicePixelRatio`	`number`	`window.devicePixelRatio`	Pixel ratio for high-DPI displays
`resetOnPlay`	`boolean`	`false`	Reset animation to frame 0 when playback starts

useSequence Hook

For more control, use the useSequence hook directly:

import { useSequence } from '@/components/image-sequence'

function MyComponent() {
  const { state, getFrame, getFrameByProgress } = useSequence({
    frameCount: 71,
    getImagePath: (idx) => `/frames/frame_${idx}.webp`,
    preload: true,
    onAllFramesLoaded: () => console.log('Ready!'),
  })

  // state.initialFramesLoaded - first and last frames are ready
  // state.loadedCount - number of frames loaded
  // getFrame(index) - get image for specific frame
  // getFrameByProgress(0.5) - get image at 50% progress
}

Binary Loading Strategy

The hook uses a binary loading strategy for progressive playback:

First and last frames load first
Then the middle frame
Then middles of each half
Continues recursively until all frames load

This ensures the full animation range is visible early at low framerate, progressively smoothing out as more frames load.
